90 Degree Chrome Plated Hand Control Valve 1/2 *3/8 Water Inlet
Brass Angle Valve
(Model NO:233NTB)
►Product Description
| Item Name | Water Inlet Brass Angle Valve |
| Modle | 233NTB |
| Color | Rose Gold |
| Weight | 155g |
| Material | Brass |
| Size | 1/2 * 3/8 |
| Surface | Polished And Chrome Plated |
| Open Method | Quick Open |
| Style | Morden |
| Installation | Screw Installation |
| Connection | Female Thread X Female Thread |
| Fuction | Connect the Water inlet and outlet of the faucet |
| Working Medium | Water |
| Quality Guarantee | 3 Years |
| OEM/ODM Acceptable | YES |
| Port | Ningbo / Shanghai |
►Product Features
Smooth surface with Multilayer electroplating ,
Quickly out of the water,
600 thousand switch operation and durable without leakage
►Details
►Technical Specifications
| Working Water Pressure | 0.05-0.8Mpa |
| Cartridge Life Time | No Leakage After 500,000 Times Using |
| Water Press For Leakage Test | 10Kgs, No Leakage |
| Water Flow | Angle Valve≥4L/ Min |
| Maximum Temperature | 90 ℃ |
| Max.Turnimg Angle | 90 Degree |
| Burst Test Pressure | Static Water Pressure Max,3.5Mpa |
| Break Torque Test | ≥15N.M |
| Lever Torque Test | 0.08-0.18N.M,Left And Right Rotation Torque Test When Static |
►Packaging & Delivery
Packing:Packed in a bag . Then put in a colorful paper box.
Delivery:15-30 days after payment.
►Competitive Advantages
1 , High quality product and competitive price
2 , Reply within 2 hours
3 , Good after-sale service
4, Professional and fast packaging team
5 , Flexible payment terms
6 , Our products have been exported to UK, France, Germany,USA,
Italy, Korea,Vietnam and many other countries.
